PEGAS II SM L

DISC / HARROWS

The new generation of disc cultivators with discs with a diameter of 620 mm ensures high-quality mixing and cutting of the soil up to a depth of 18 cm.

Product description

PEGAS II SM L disc cultivators are characterized by high-quality work on stubble, mainly thanks to large discs with a diameter of 620 mm. Together with the 130 cm spacing between the disc rows, they ensure high-quality soil mixing and loosening without the risk of clogging the machine, even with a large amount of post-harvest residues. The machine can also be equipped with front tools for processing greening or rough pre-sowing preparation.
PEGAS II SM L
PEGAS II SM L

The main advantage of the machine

The 620 mm diameter discs can handle even demanding conditions and ensure precise cultivation up to a depth of 18 cm.

Equipment

Basic equipment

  • semi-mounted version
  • double-row disc harrows with individually sprung discs
  • disc diameter 620 mm
  • spacing between the 1st and 2nd row of discs 130 cm
  • overload protection with rubber rollers secured against ejection
  • working depth up to 18 cm
  • double-row maintenance-free ball bearings for discs
  • support tube roller 550 mm
  • suspension shaft cat. 3, ball center distance 870 mm
  • possibility of aggregation with a seeder APV PS 120 M1 – PS 200 M1
  • braked axle only on the machines PEGAS II SM 5/6

Additional equipment

  • ⌀ 600 mm cracker roller
  • ⌀ 600 mm u-ring roller
  • ⌀ 600 mm double u-ring roller
  • The tube bar and flat bar rollers ⌀ 400/400 mm
  • ⌀ 515 mm rubber roller
  • crossboard
  • APV seed spreader holder
Variation – ⌀ 600 mm cracker roller
Variation – ⌀ 600 mm u-ring roller
Variation – ⌀ 600 mm double u-ring roller
Variation – The tube bar and flat bar rollers ⌀ 400/400 mm
Variation – ⌀ 515 mm rubber roller
Variation – crossboard
Variation – APV seed spreader holder

Technical parameters

Technical parameters PEGAS II SM L 4 PEGAS II SM L 5 PEGAS II SM L 6
Working width (m) 4 5 6
Transport width (m) 3 3 3
Number of discs (pcs) 32 40 48
Tractor output (hp) 150 - 200 190 - 250 230 - 300
Weight (kg) 3970 4630 5130
